Removing the Bezel, Cover, and Front Panel

This procedure is best performed with the system on its side (see Figure 1-4).

1

Remove the bezel and set it aside:

a

Using the system key, unlock the bezel.

b

Pull the bezel away from the system so that it is perpendicular to the system (see

Figure 1-4).

c

Loosen the thumbscrews to release the bezel (see Figure 1-4).

d

Pull the bezel away from the chassis.

Figure 1-4. Removing or Replacing the Front Bezel

thumb screws (2)

mounting
holes (2)

R a c k - t o - T o w e r C o n v e r s i o n G u i d e |

1-9
