AT-10
FAA Transmission Set-Up Instructions
Push the MEMORY button
Select 2 Settings
The following window will appear:
1 Select data for resting ECG
2 Select data for exercise ECG
3 Configuration of transmission
4 Phone No. Modem
5 Init. Modem
6 Further settings
Select 1: select data for resting ECG
Make sure the unit is configured the following way:
Select records for transmission:
Interpretation
<1>: yes
Intervals and axis <2>: No
Measurements <3>: yes
Average cycles (orig. data) <4>: No
Lead R1: V1 (compressed data) <5>: No
Lead R2: II (compressed data) <6>: No
12 leads (compressed data) <7>: No
12 leads (original data) <8>: No
ECG (SCP-ECG) <9>: yes
Press ESC to get out of this menu
Select 3 Configuration of transmission
Make sure the unit is configured the following way:
Kind of transmission
<1>: Modem: protocol =CCITT
-----------------Mode setting RS-232/422-------------------
Channel:
<2>: RS-232
Baud <3>: 38400
Parity <4>: No
Stop <5>: 1
Press ESC to exit this menu
Select 4 Phone No. Modem
Select T for Tone
Enter 9 if you need an outside line and place a comma after 9 to
pause the modem when dialing out
Enter FAA phone number (405) 954-1971. See chart.
Press Enter to save
Press ESC to exit this menu
Enter one of the following options:
Long Distance: 14059541971
Long distance plus outside line:
9,14059541971
Local call plus outside line:
9,9541971
Local call: 9541971
Use the Yes + or No- keys on the
AT-10 keypad to toggle between
Yes and No
Use the Up & Down arrow keys on
the AT-10 keypad to move from one
field to the another
71023-0001A Page 1 of 2
