11. Select: 2 or 3 channel and 24 or 48 hour recording duration. Connect patient and click Next.
12. The following message indicates that the previously recorded test on this SD card has not been
downloaded.
• If you want to retrieve the data, click No and go to “Retrieving Data When Patient Returns With
Holter Recording Completed”.
• If you want to overwrite the data, click Yes.
13. Verify signal quality (i.e. amplitude and artifact). QRS signal amplitude should be two boxes peak to
peak. Select Finish. Test Startup is complete.
Retrieving Data When Patient Returns
With Holter Recording Completed
1. Open recorder door and remove battery.
2. Remove SD card from recorder.
3. Be sure the Holter software application is running and insert an SD card into the SD card reader
connected to the computer.
4. The Holter software application will upload and analyze the recorded test information automatically.
Monitor the progress in the lower right hand corner of your screen.
WA Holter System
SD Card contains a data file. Do you wish to overwrite?
Yes No
