Enter manual parameters
1. From the Home tab, touch anywhere within the Manual parameters frame. The Manual tab appears.
2. Touch the up/down arrow keys or the keypad to manually adjust height, weight, pain level, temperature,
respiration rate, or other parameters.
3. Touch OK to confirm settings and return to the Home tab.
Note Entries will not be saved unless you touch OK.
Set modifiers
1. Touch the Patients tab.
2. Touch the Modifiers tab.
3. Adjust the settings as required.
4. Touch
OK to accept or Clear to delete all entries.
Note Entries will not be saved unless you touch OK.
