Pocketscope transilluminator, Lamp replacement – Welch Allyn PocketScopes - User Manual User Manual
Page 12
10
PocketScope
Transilluminator
TransilluminatorFeatures
• FiberOptictransmissionforbrightcoollight
transmission.
• Curveddesigntofitintotightareas.
TransilluminatorAttachment
Removetheretinoscopebyturningthe
instrumentinacounterclockwisedirection.
Thiswilldisconnecttheretinoscope.
Connect the transilluminatorbyturningthe
instrumentinaclockwisedirection.
Lightpipecanberotatedtolocateoptimum
orientation.
Instructionsforattachingthetransilluminator
Lamp Replacement
RetinoscopeLampReplacement
1. Remove(unscrew)
retinoscopehead.
2. Graspendoflampand
pullout(usenailfileor
similarobjectif
necessary).
