SYSTEM DESCRIPTION

The Welch Allyn Light Source is used to supply high quality, white light
for video and optical illumination systems. It accepts standard ACMI
connectors.

FRONT

BACK

BOTTOM

Power Switch

Fiber Optic
Bundle Port

Light
Control Knob

Fan Grill

AC Power
Input

Lamp Access
Knob

Mounting Post

Fuse Drawer

Mounting Bracket
