6
"A"
"B"
"C"
"D"
"E"
DOOR STYLE
(G) Glass Frame Door
(F) Frame Glass Overlay Door (no handle)
If necessary to gain clearance inside
the rough-in opening a hole can be cut
through the adjacent cabinet and the
power cord routed through this hole to a
power outlet. Another way to increase the
available opening depth is to recess the
power outlet into the rear wall 1" (2.5 cm)
to gain the thickness of the power cord
plug.
PRODUCT DIMENSIONS
Figure 5
Figure 5a
ROUGH-IN OPENING DIMENSIONS CABINET DIMENSIONS
MODEL "A" "B" "C" "D" "E" "F" "G" "H" "J"
MP15WSG
15"
(38.1 cm)
**34" to 35"
(86.4 to 88.9 cm)
*
14 7 ⁄
8
"
(37.8 cm)
33 3 ⁄
4
" to 34 3 ⁄
4
"
(85.7 to 88.3 cm)
23 23 ⁄
32
"
(60.2 cm)
26 7 ⁄
32
"
(66.6 cm)
37 13 ⁄
32
"
(95 cm)
17 7 ⁄
16
"
(44.3 cm)
MP15WSF
15"
(38.1 cm)
**34 1 ⁄
4
" to 35 1 ⁄
4
"
(87 to 89.5 cm)
*
14 7 ⁄
8
"
(37.8 cm)
34" to 35"
(86.4 to 88.9 cm)
22 7 ⁄
8
"
(58.1 cm)
-
37 1 ⁄
2
"
(95.2 cm)
14 1 ⁄
8
"
(35.9 cm)
MP24**G
24"
(61 cm)
**34" to 35"
(86.4 to 88.9 cm)
*
23 7 ⁄
8
"
(60.7 cm)
33 3 ⁄
4
" to 34 3 ⁄
4
"
(85.7 to 88.3 cm)
23 23 ⁄
32
"
(60.2 cm)
26 7 ⁄
32
"
(66.6 cm)
46 13 ⁄3
2
"
(117.9 cm)
26 7 ⁄
16
"
(67.2 cm)
MP24**F
24"
(61 cm)
**34 1 ⁄
4
" to 35 1 ⁄
4
"
(87 to 89.5 cm)
*
23 7 ⁄
8
"
(60.7 cm)
34" to 35"
(86.4 to 88.9 cm)
22 7 ⁄
8
"
(58.1 cm)
-
46 1 ⁄
2
"
(118.1 cm)
23 1 ⁄
8
"
(58.7 cm)
