AIRSHORE Struts and Accessories for Rescue
Base plate, clevis, strut, extension and V-attachment
Example for extensions
ART-E6 toART-E24
Example for extensions
ART-E36 toART-E72
Angle attachment
ART-VB
Angle attachment
ART-VB
Extension ART-E 24
610 mm
!ATTENTION! A ma-
ximum of just one
extension can be used
per strut!
Extension ART-E 36
915 mm
!ATTENTION! A ma-
ximum of just one
extension can be used
per strut!
ART-STRUT, ART-B
660 - 940 mm
ART-STRUT, ART-E4.5-7
1370 - 2130 mm
Bracket
ART-PC
Bracket
ART-PC
Base plate 150 mm
ART-BP6
Base plate 150 mm
ART-BP6
