4
TECH CORNER
Additional Information you may find useful
1. CONTROLLER: The controller turns off power to the load at 11V and
reconnects when the battery reaches 12V. This protects battery from
overdischarge and increases battery life and performance.
2. CAPACITY: The RemotePro RPPL is rated at 8W continuous
power output with 6 hours of peak sun per day. Reserve battery capaci-
ty at 8W load is 27 hours.
SPECIFICATIONS
Subject to change without notice
RPPL12 RPPL24
Continuous Power Rating 8W
Maximum Power Rating 30W
Reserve Power @ 8W Load 27 hours
Battery Voltage (DC) 12V 24V
POE Output Voltage (DC) 12V, 18V, 24V or 48V 24V
POE Input Voltage (DC) 18-57V 36-57V
Battery Capacity 36Ah 18Ah
Battery Type
Valve Regulated Sealed Lead Acid / Absor-
bent Glass Mat (AGM)
Battery Life 5 Years
Controller Type
Dual Input Solar/POE,
PWM,
12V 8A
Max Solar Panel Size
135W
Dual Input Solar/
POE, PWM,
24V 8A
Max Solar Panel Size
270W
Overcharge Protection 14.4V 27.3V
Over-discharge protection 11V 20V
Over-discharge recovery 12V 22.3V
Self Consumption <0.5W
Enclosure Type Polycarbonate
Enclosure External Size
17.5 x 12.5 x 6”
(445 x 318x 152mm)
Enclosure Internal Size
14 x 10 x 5”
(356 x 254 x 127mm)
Space for Customer Equip
3 x 5 x 3”
(76 x 127 x 76mm)
Operating Temperature
-
30°C to +60°C
System Weight (no batts) 4lb (1.8kg)
Battery Weight (each) 2.5kg (5.5lb)
