User’s Manual

TP-MS308/316/324



31

5. Technical Specification

PARAMETER

TP-MS308

TP-MS316

TP-MS324

Data Ports

8

16

24

PoE Ports

8

16

24

Pass through Data Rates

10/100/1000Mbps

Console Port

1× RJ45 console interface for management

Output power

Per port DC 48V@350mA 16.8W(Maximum)

Pair4/5(+),Pair7/8(-)

Disconnection

AC Disconnect

(AC Disconnect and DC Disconnect display the detect

scheme being used and are for information only)

Power consumption

(maximum)

134W

268W

403W

AC Input

100~240VAC,50/60Hz

DC Input

DC -48V(-42V~-57V)

Environment

Operating Temperature: 0

℃~65℃

Storage Temperature: -20

℃~80℃

Humidity: 10%~95%RH (non condense)

Dimensions

430mm(L) x 290

mm(W) x 44mm(H), 19” Rack-Mount / 1U

Weight

3.2kg

3.9kg

4.6kg
