User’s Manual

TP-MS308/316/324



27

Port Status

In the

“Module” window, select the suitable port that you require, then, click

“StatusDisp”, and select “PortStatus”, or click the “PORT STATUS” icon, the screen

will show current status of each port and current power supply status of each

module.

If all power modules are working normally, the

“Sys. Power” will show a green light, if

any module has failed, the light will turn to red.
