there is 115 VAC across the T6 and T9 terminals on XCOP1 control, verify that RT-Series Fan motor capacitor is good.
Disconnect the wire from capacitor that is connected to the ORG Motor terminal on XCOP1 control. Reconnect Orange wire from
RT-Series Fan capacitor in 4 x 4 electrical box to the Orange wire that should be capped off coming from RT-Series Fan whip.
Remove the Red and White/Red leads that were connected to the MOTOR RED and WHT/RED connection on XCOP1 and pro-
vide 115 VAC to them. If motor runs, replace COP control circuit board part number 950-8805. If motor does not run, verify capaci-
tor is good. Replace RT-Series Fan capacitor or motor if necessary.

HOW TO OBTAIN SERVICE ASSISTANCE

If you have any questions about your XCOP1 or if it requires adjustment or repair, contact your installer, contractor or service
agency.

If you require technical information contact Tjernlund Products, Inc. at 1-800-255-4208 with the following information.

1. Model of the RT-Series Fan that XCOP1 is interlocked with as shown on the label attached to RT-Series Fan.

2. Name and address of installer and any service agency who performed work on the system.

3. Date of original installation and dates any service work was performed.

4. Details of the problem as you can best describe them.

LIMITED PARTS WARRANTY AND CLAIM PROCEDURE

Tjernlund Products, Inc. warrants the components of the XCOP1 for one year from date of installation. This warranty covers
defects in material and workmanship. This warranty does not cover normal maintenance, transportation or installation charges for
replacement parts or any other service calls or repairs. This warranty DOES NOT cover the complete XCOP1 if it is operative,
except for the defective part.

Tjernlund Products, Inc. will issue credit or provide a free part to replace one that becomes defective during the one year warranty
period. Proof of date of the installation in the form of the contractor sales/installation receipt is necessary to prove the unit has
been in service for under one year. All receipts should include the date code of the XCOP1 to ensure that the defective component
corresponds with the complete unit. This will help prevent possible credit refusal.

1.) Follow troubleshooting guide to determine defective component. If unable to determine faulty component, contact your

Tjernlund distributor or Tjernlund Technical Customer Service at 1-800-255-4208 for troubleshooting assistance.

2.) After the faulty component is determined, return it to your Tjernlund distributor for replacement. Please include XCOP1 date

code component was taken from. The date code is located on the Electrical Box cover. If the date code is older than one
year, you will need to provide a copy of the original installation receipt to your distributor. Credit or replacement will only be
issued to a Tjernlund distributor after the part has been returned prepaid to Tjernlund and verified defective.

WHAT IS NOT COVERED

Product installed contrary to our installation instructions, altered, neglected or misused

Product that has been wired incorrectly

Any freight charges related to the return of the defective part

Any labor charges related to evaluating and replacing the defective part

T COVERED

REPLACEMENT PARTS

Component

Part Number

COP Control Circuit Board

950-8805

TJERNLUND LIMITED ONE YEAR WARRANTY

Tjernlund Products, Inc. warrants to the original purchaser of this product that the product will be free from defects due to faulty material or work-
manship for a period of (1) year from the date of original purchase or delivery to the original purchaser, whichever is earlier. Remedies under
this warranty are limited to repairing or replacing, at our option, any product which shall, within the above stated warranty period, be returned to
Tjernlund Products, Inc. at the address listed below, postage prepaid. THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE
DESCRIPTION ON THE FACE HEREOF, AND TJERNLUND PRODUCTS, INC. EXPRESSLY DISCLAIMS LIABILITY FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES ARISING FROM THE USE OF THIS PRODUCT. THIS WARRANTY IS IN LIEU OF ALL OTHER EXPRESS
WARRANTIES AND NO AGENT IS AUTHORIZED TO ASSUME FOR US ANY LIABILITY ADDITIONAL TO THOSE SET FORTH IN THIS LIM-
ITED WARRANTY. IMPLIED WARRANTIES ARE LIMITED TO THE STATED DURATION OF THIS LIMITED WARRANTY. Some states do
not allow limitation on how long an implied warranty lasts, so that limitation may not apply to you. In addition, some states do not allow the
exclusion or limitation of incidental or consequential damages, so that above limitation or exclusion may not apply to you. This warranty gives
you specific legal rights and you may also have other rights which may vary from State to State. Send all inquiries regarding warranty work to
Tjernlund Products, Inc. 1601 9th Street, White Bear Lake, MN 55110-6794. Phone (651) 426-2993 • (800) 255-4208 • Fax (651) 426-9547 •
Email [email protected].
