Symtech LCA2 EZ - Manual (Page 2)

INDEX
1. GENERAL Pg. 3
1.1 “LCA 2 EZ ” INTRODUCTION
1.2 SYSTEM COMPONENTS
1.3 LASER WARNING
1.4 “VISUAL ASSIST” METER & SWITCH
2. ASSEMBLY Pg. 4
2.1 BASE / WHEEL ATTACHMENT
2.2 MAST / GLIDE PLATE / ROTATIONAL MAST MOUNT
2.3 OPTICAL ALIGNMENT HEAD
2.4 SIGHTING UNIT
2.5 SIGHTING UNIT CALIBRATION
2.6 FLOOR SLOPE LASER
3. OPERATION Pg. 6
3.1 ALIGNMENT BAY(s) PREPARATION
3.2 FLOOR SLOPE MEASUREMENT
3.3 VEHICLE PREPARATION, Prior to Alignment
4. HEADLAMP ALIGNMENT PG. 7
4.1 ALIGNMENT of OPTICAL HEAD TO VEHICLE
4.2 CENTERING on the HEADLAMP
4.3 SELECTING HEADLAMP PATTERN
4.4 ALIGNMENT of HEADLAMP PROCEDURE
5. LASER CALIBRATION / MAINTENANCE Pg. 9
5.1 LASER CALIBRATION
5.2 MAINTENANCE
6. FREQUENTLY ASKED QUESTIONS Pg. 10
WARRANTY Pg. 11
CUSTOMER SERVICE
888-884-8182
