TX Data.
Blinks when EX500 transmit to the network.
R
RX Date.
Blinks when other devices transmit to the network.
SWITCH PROGRAMMING
SW2 on PCB1001 is the crisis alert network address.
Network 1 Node 0 is normally used (Address $08):
1
2
3
4
5
6
7
8
OFF
OFF
OFF
ON
OFF
OFF
OFF
OFF
SYSTEM MEMORY DEFAULT
The memory mustt be initialized when the system is first installed. All programmable features are
set to factory default and all station are assigned call numbers .
Single stage:
SW3 on PCB500 (EX500) is used for selecting number of digits in call numbers when the system is
defaulted.:
1
2
OFF
OFF
Special preprogrammed configuration (Reserved)
OFF
ON
2 Digit Dialing (10-55)
ON
OFF
3 Digit Dialing (100-155)
ON
ON
4 Digit Dialing (1000-1055)
1.
Set all 8 dip switches in SW2 (EX500) to OFF.
2.
Set SW3 (EX500) for number of call digits.
3.
Push and release the Reset Switch on EX500 (SW4).
LED M (EX500) will blink 4 times during RAM Test (apx. 2 sec.).
The RAM will initialize (1 sec.).
LED M will flash rapidly to indicate that the initialization is complete.
4.
Set SW2 (EX500) to proper network address (turn switch 4 ON)
5.
Push and release the Reset Switch on EX500 (SW4).
LED M (EX500) will blink 4 times during RAM Test .
The system is now operational.
