RM5000EX Operations Manual March 2011
PERSONAL QUEUE
Each intercom station has a Personal Queue. This queue is activated with Privelege ID number 7.
All received calls are put in personal que and the intercom station will ring (2 sec on, 3 sec off) until
the call is answered by pressing the 0 key. When the call is cancelled (X) the next call in queue starts
ringing after 2 seconds. This time is programmable (Timer ID number 6).
Calls are inserted to the personal queue on a first in first out within each priority level (1-9). The
priority level is the Call Priority of the calling station (level 1 is highest priority). The calling station
may be connected to Ringing Tone, Program Channel or silence when in que.
PROGRAMMING
The following commands are used for this feature
SPT
Set Privilege Type
SST Set Subscriber Timer
SQP Set Que Program Channel
SCP Set Call Priority
LPT List Privilege Type
LST List Subscriber Timer
LCN List Call Number
Example: Intercom station 10 is using personal queue to receive calls with 1 second delay between
calls. Intercom stations 11-14 will get ringing tone when they call intercom 10. Intercom 11 will get
calling priority 3 and intercom 12-14 will get priority level 4.
>SPT
cr
Call Number <10-99/*> : 10
cr
Privilege ID <1..7> : 7
cr
<+/-/=> : +
cr
>SST
cr
Call Number <10-99/*> : 10
cr
Timer ID <1..8> : 6
cr
Timer Value <0....240> :1
cr
>SQP
cr
Call Number <10-99/*> : 11-14
cr
Program Channel in QUE (0=None, 1=Program, 2=Ringback) <0..2> : 2
cr
>SCP
cr
Call Number <10-99/*> : 11
cr
Priority Level <1..9> : 3
cr
>SCP
cr
Call Number <10-99/*> : 12-14
cr
Priority Level <1..9> : 4
cr
>
