March 2011 Operations Manual RM5000EX
FIREALARM
Group Conference used for Emergency Communication/Paging. DS16 used for Login display and
Faults
Example:
10
AA916 Master station with Annunciator for Log In Display and Faults DS16 ($09).
11-24 SS912/AN913EB Stations with Log In and Push ToTalk buttons.
25
IF935 Paging Interface.
Programming:
Master station 10.
SNA 10 1 09 (DS16 assigned to master station)
SPT 10 7 + (Activate Personal Que)
SPT 10 5 + (Activate Group Call Access)
Fire Stations 11-24.
SDA 11-24 10 (Log In and Faults are sent to 10)
SPT 11-24 10 + (Line Supervision)
SPT 11-24 13 + (Activate Log In Display)
SDD 11-24 3 91 (Log In activated by direct dial 3)
Paging Interface 25.
SDT 25 1 (Sub)
SDA 25 10 (Faults are sent to 10)
SPT 25 10 + (Line Supervision)
Group Call 1 (71).
SGCM 10-25 1 + (Include stations 10 -25 in group call #1)
SGCP 1 2 + (T button must be used when talking)
SGCP 1 3 + (Activate Group Conference)
SST 10-25 4 00 (Set Group Call time limit to unlimited)
Page33
