INSTALLATION
POWER HOOKUP
Use DC power supply.
Connect +24VDC to TB1 pin 1
Connect Ground (minus) to TB1 pin 2
PROGRAM DISTRIBUTION
TB2 pin 1 Audio inn +
TB2 pin 2 Audio inn -
TB2 pin 3 No Connection
TB2 pin 4 No Connection
CRISIS ALERT NETWORK
The EX500 has a one pair RS485 bidirectional port for communication with Crisis Alert Devices:
DNA100 Used for programming or for interfacing to Log Printer
DNA200 Camera switcher Interface
DNA300 Computer Control Interface
DNA400 Pocket Page Interface
DAD104 Annunciator Display
DS16 Direct select Annunciator, 16 line
TB3 pin 1 Data +
TB3 pin 2 Data -
TB3 pin 3 +24V out (fused)
TB3 pin 4 Ground (minus)
TB3 pin 5 External Alarm
TB3 pin 6 External Alarm
The DNA100 can be connected directly to J1 for programming.
The EX500 has 3 LEDs for displaying network communication:
M Master LED. This LED is ON if the EX500 is the Master on the Network.
