a certain distance to the unit. Objects situated between the visualizer and
the infrared remote control and a weak battery may interfere with the
reception.
On the left side of the visualizer stage, there is a built-in remote control
storage compartment where you can store the remote control when you not
use it.
PRESET FUNCTION
Use the “SET” button to preset 4 steps of the Zoom/Focus position, when
the button is pressed, it moves step by step. Press “RUN” button to the run
preset. (On the remote control)
2 X 2 MULTIPLE SCREEN DISPLAY
Press “Mem”, the stored images can be displayed in a 2 x 2 matrix. Press
“Mem” once, the stored first four images can be displayed in a 2 x 2 matrix.
Press the
button to display the upper left image; press the button
to display the upper right image; press the button to display the lower
left image; press the button to display the lower right image. Press
“Mem” twice, the stored second four images will be displayed in a 2 x 2
matrix, the operation of
, , , is the same. Under this operation,
the “Frz”, “Neg”, “Far” and “Near” button do not function. Press “Mem” the
fifth time to exit the 2 x 2 image display mode.
On the remote control, the “RECALL”,“ ”, “ ”, “
” and “ ” button can do
the operation.
USB PORT
The USB port can be used to store still images from the visualizer in a
computer. No additional computer hardware is required. In this way, the
visualizer can be used as a 3-D scanner for your computer.
Connect the Visualizer to your computer with the supplied USB cable.
The Visualizer Software is available on the supplied CD-ROM.
18
