installation manual

13

Fig.6-12

Fig.6-11

>30cm /11.81in

>30cm

/11.81in

>30cm

/11.81in

>30cm

/1

1.81in

Air inlet

Air inlet

Air inlet

Air inlet

Fig.6-10

(Wall or obstacle)

≥40

0

/15.75in

≥300

/11.81in

≥30

0

/11.81in

a)

In case that suspending in the ceiling

b)In case that installing on the floor

≥300

/11.81in

≥40

0

/15.75in

≥300

/11.81in

3. Centrifugal fan type outdoor unit

6.4 Available configuration for centrifugal fan

type outdoor unit

All the figures in this manual are for explanation

purpose only. They may be slightly different from the air

conditioner you purchased.The actual unit shall prevail.

NOTE

NOTE

Four different configuration are available for oudoor unit only
changing the panels and fan position.

Keep in mind that fan unit weight is aprox 30kg/1058oz ,the unit
as well as relevant equipment covered with the vinyl cover
during installation work.

To change air inlet is only necessary to interchange the
indicated panels position. Both panels

use

screws to be fixed

to unit chas

s

is.

To change air outlet is necessary to interchange panels too.
Fan outlet panel is attached to fan structure, which must be
mounted as

follow

.

Air inlet modification

Change Panel

Fig6-13

Fig.6-14
