Oldcastle BuildingEnvelope 6000 Series Thermal MultiPlane - Manual (Page 10)

9 


S E R I E S 6 0 0 0 T H E R M A L M U L T I P L A N E I N S T A L L A T I O N M A N U A L
OUTSIDE GLAZED, FRONT SET
FRAME ASSEMBLY
FG-6284
4"
13/
16"
typ
.
2-5
/8"
FG-6283
FG-6296
FG-6294
FG-6281 standard
FG-6280 low profilel
Reference page 22 for use of DJ-10 drill fixture.
1/4
"
13/
16"
3/4
"
typ
.
2-5
/8"
"F" (0.257 dia)
drill typ
Sealant
exterior
only
Top of
horizontal
Apply silicone sealant
4" up interior snap joint
Apply silicone sealant
in glazing reglet of vertical
where it marries with sealant
applied to the horizontal
FG-3278
HP-17
Apply silicone
sealant to end of
horizontals as
shown
FS-8 (typ)
part # 10223
1-1
/2"
1 3
/4"
@ F
G-6
281
1 1
/4"
@ F
G-6
280
