Getting Started
NOTE:
Getting Started
Step 1
Step 3
Step 4
Step 2
Before you start running your new Mini-Monster Baja, it is absolutely necessary that you
read through all of the operating instructions to prevent unnecessary damage and get the
maximum enjoyment from your vehicle.
Plug the AC charger into the proper wall receptacle (110v-240v)
notice the small light (LED) will glow green. When you connect
the battery to charge the LED will turn red. The last 5 minutes
of the charge the LED will flicker Red to Green. Disconnect
the battery when the LED turns green - charging is done. After
running or when the Baja slows noticeably, wait 10 minutes for
the battery to cool and recharge.
Remove the transmitter battery cover by sliding the cover
from left to right. Install four (4) AA batteries into the battery
holder. Pay close attention to the correct direction of the
positive (+) and negative (-) ends as marked in the tray.
Once all four batteries have been installed, reinstall the
battery cover by sliding it on from right to left.
The DSM ® receiver has a short antenna that can be positioned
underneath the body as shown in Fig. 1
Once the battery
is charged,
remove the body
clip from the front
of the battery tray
(fig. 2) and lift
up the front of
the tray (fig. 3).
Install the battery
pack as shown
(fig. 4), reinstall
the body clip and
plug the battery
pack into the
ESC.
Fig 1
Fig 2
Fig 3
Fig 4
