StEp 4
Install the charged battery pack into the chassis as shown.
Ensure the battery is laying flat on the chassis.
StEp 5
Reinstall the battery strap and body clip. Plug the battery
pack into the ESC.
StEp 6
Off On
Always turn on the transmitter first. The small red and green
lights above the switch should both light up. If not, you need
to check for low or incorrectly installed batteries.
StEp 7
Once the transmitter has been powered on, turn on your
vehicle by sliding the switch on the ESC to the “ON” position.
StEp 8
Forward
Brake/Reverse
TH Trim
Left Right
ST Trim
If the rear wheels turn during power-on, adjust the “TH. Trim”
knob located to the lower right of the steering wheel until they
stop.
To make the vehicle move forward, pull the trigger back. To
reverse the vehicle, wait for the model to stop and then push
the trigger forward.
When going forward the vehicle should move in a straight
line. If not, adjust the “ST. Trim” so that it tracks in a straight
line without having to turn the steering wheel.
StEp 9
After you have finished, turn your vehicle off FIRST by sliding
the ESC switch to the “OFF” position. After the model has
been turned off, turn off the transmitter.
StEp 10
If you wish to clean your vehicle, use compressed air and/or
a soft brush to remove dust and dirt. NEVER use chemicals
or anything wet as it can cause damage to both electronics
and plastic parts.
