esc SPECIFICATIONS
� Supports LiPo / NiMh battery type
� 2 different modes:
1. Forward/Reverse & Smart Brake Mode
2. Forward only Mode
� One touch setup
� LED indicator
Immediately after ESC is turned ON (for 2 sec):
Only the RED LED flashing = LiPo Battery
Only the GREEN LED flashing = NiMh Battery
During Normal Operation:
Stop/Neutral (Depends on Mode)-Fwd/Reverse Mode = GREEN LED on solid
Stop/Neutral (Depends on Mode)-Forward Only Mode = GREEN LED flashing fast
Forward (not full speed) = All LED’s are OFF
Forward (full speed) = Red LED is ON
Reversing (not full speed) = All LED’s are OFF
Reversing (full speed) = Red LED is ON
Brake (full brake) = Red and Green LED is ON
Overheated = Flashing of Red and Green LED’s
� Thermal protection
If the ESC gets overheated it will shut off power output automatically, and the red and green LEDs
will alternate flashing for 30sec. After 30 sec, the ESC will return to normal operation.
� Over load protection
When the motor is stalled the ESC will automatically shut off the power output with the red LED
flashing for 30seconds. After 30 seconds the ESC will return to normal operation.
Note
!
The ESC will remain in brake mode until the throttle is returned to the neutral
position for a short time before moving it in the opposite direction.
� Electrical Specifications:
Forward:
- Max instantaneous Current : 75A
- Max continuous Current : 15A
- On resistance : 0.004 ohm
PWM frequency : 1 kHz
Operation Voltage : 4.8V ~ 8.4V
BEC : 5V/1A max at 7.2V
� Smart Brake:
When the throttle is moved from Forward to Reverse or Reverse to Forward, the ESC will go into
brake mode instead of allowing the motor to go into reverse immediately.
� Voltage Protection (NiMh or LiPo)
The user can select either 6V cutoff (Red LED for LiPo) or 4V cutoff (Green LED for NiMh).
When the input voltage becomes less than the selected value/battery type the ESC will
automatically shut off the power output to protect the battery from over discharging.
Reverse:
- Max instantaneous Current : 75A
- Max continuous Current : 10A
- On resistance : 0.006 ohm
