19
COMe-cTH6 User’s Guide
www.kontron.com
Pin Signal Description Type Termination Comment
C42 DDI3_PAIR1+ Digital Display Interface DP-O
C43 DDI3_PAIR1- Digital Display Interface DP-O
C44 DDI3_HPD Digital Display Interface Hot-plug detect I-3.3
C45 RSVD10 Reserved Not connected nc nc
C46 DDI3_PAIR2+ Digital Display Interface DP-O
C47 DDI3_PAIR2- Digital Display Interface DP-O
C48 RSVD11 Reserved Not connected nc nc
C49 DDI3_PAIR3+ Digital Display Interface DP-O
C50 DDI3_PAIR3- Digital Display Interface DP-O
C51 GND36 Power Ground PWR - -
C52 PEG_RX0+ PCI Express Graphics Receive Lane 0 Positive DP-I
C53 PEG_RX0- PCI Express Graphics Receive Lane 0 Negative DP-I
C54 TYPE0 Not connected for Type 6 module Not connected nc nc
C55 PEG_RX1+ PCI Express Graphics Receive Lane 1 Positive DP-I
C56 PEG_RX1- PCI Express Graphics Receive Lane 1 Negative DP-I
C57 TYPE1 Not connected for Type 6 module Not connected nc nc
C58 PEG_RX2+ PCI Express Graphics Receive Lane 2 Positive DP-I
C59 PEG_RX2- PCI Express Graphics Receive Lane 2 Negative DP-I
C60 GND37 Power Ground PWR - -
C61 PEG_RX3+ PCI Express Graphics Receive Lane 3 Positive DP-I
C62 PEG_RX3- PCI Express Graphics Receive Lane 3 Negative DP-I
C63 RSVD12 Reserved Not connected nc nc
C64 RSVD13 Reserved Not connected nc nc-
C65 PEG_RX4+ PCI Express Graphics Receive Lane 4 Positive DP-I
C66 PEG_RX4- PCI Express Graphics Receive Lane 4 Negative DP-I
C67 RSVD14 Reserved Not connected nc nc
C68 PEG_RX5+ PCI Express Graphics Receive Lane 5 Positive DP-I
C69 PEG_RX5- PCI Express Graphics Receive Lane 5 Negative DP-I
C70 GND38 Power Ground PWR - -
C71 PEG_RX6+ PCI Express Graphics Receive Lane 6 Positive DP-I
C72 PEG_RX6- PCI Express Graphics Receive Lane 6 Negative DP-I
C73 GND39 Power Ground PWR - -
C74 PEG_RX7+ PCI Express Graphics Receive Lane 7 Positive DP-I
C75 PEG_RX7- PCI Express Graphics Receive Lane 7 Negative DP-I
C76 GND40 Power Ground PWR - -
C77 RSVD15 Reserved Not connected nc nc
C78 PEG_RX8+ PCI Express Graphics Receive Lane 8 Positive DP-I
C79 PEG_RX8- PCI Express Graphics Receive Lane 8 Negative DP-I
C80 GND41 Power Ground PWR - -
C81 PEG_RX9+ PCI Express Graphics Receive Lane 9 Positive DP-I
C82 PEG_RX9- PCI Express Graphics Receive Lane 9 Negative DP-I
C83 RSVD16 Reserved Not connected nc nc
C84 GND42 Power Ground PWR - -
C85 PEG_RX10+ PCI Express Graphics Receive Lane 10 Positive DP-I
C86 PEG_RX10- PCI Express Graphics Receive Lane 10 Negative DP-I
C87 GND43 Power Ground PWR - -
C88 PEG_RX11+ PCI Express Graphics Receive Lane 11 Positive DP-I
