Kontron COMe-cTH6 User Manual
Page 20
14
COMe-cTH6 User’s Guide
www.kontron.com
Pin
Signal
Description
Type
Termination
Comment
A36
USB6-
USB Data- Port #6
DP-I/O
-
A37
USB6+
USB Data+ Port #6
DP-I/O
-
A38
USB_6_7_OC
USB Overcurrent Pair 6/7
I-3.3
A39
USB4-
USB Data- Port #4
DP-I/O
A40
USB4+
USB Data+ Port #4
DP-I/O
-
A41
GND5
Power Ground
PWR
-
-
A42
USB2-
USB Data- Port #2
A43
USB2+
USB Data+ Port #2
DP-I/O
A44
USB_2_3_OC
USB Overcurrent Pair 2/3
I-3.3
A45
USB0-
USB Data- Port #0
DP-I/O
A46
USB0+
USB Data+ Port #0
DP-I/O
A47
VCC_RTC
RTC Power Supply +3V
PWR
-
-
A48
EXCD0_PERST
PCIe Express Card 0 Reset
O-3.3
A49
EXCD0_CPPE#
PCIe Express Card 0 Request
I-3.3
A50
LPC_SERIRQ
LPC Serial Interrupt Request
IO-3.3
A51
GND6
Power Ground
PWR
-
-
A52
PCIE_TX5+
PCIe 5 Transmit Data+
DP-O
A53
PCIE_TX5-
PCIe 5 Transmit Data-
DP-O
A54
GPI0
General Purpose Input 0
I-3.3
A55
PCIE_TX4+
PCIe 4 Transmit Data+
DP-O
A56
PCIE_TX4-
PCIe 4 Transmit Data-
DP-O
A57
GND7
Power Ground
PWR
-
-
A58
PCIE_TX3+
PCIe 3 Transmit Data+
DP-O
A59
PCIE_TX3-
PCIe 3 Transmit Data-
DP-O
A60
GND8
Power Ground
PWR
-
-
A61
PCIE_TX2+
PCIe 2 Transmit Data+
DP-O
A62
PCIE_TX2-
PCIe 2 Transmit Data-
DP-O
A63
GPI1
General Purpose Input 1
I-3.3
A64
PCIE_TX1+
PCIe 1 Transmit Data+
DP-O
A65
PCIE_TX1-
PCIe 1 Transmit Data-
DP-O
A66
GND9
Power Ground
PWR
-
-
A67
GPI2
General Purpose Input 2
I-3.3
A68
PCIE_TX0+
PCIe lane #0 Transmit+
DP-O
A69
PCIE_TX0-
PCIe lane #0 Transmit-
DP-O
A70
GND10
Power Ground
PWR
-
-
A71
LVDS_A0+
LVDS Channel A (positive)
DP-O
A72
LVDS_A0-
LVDS Channel A (negative)
DP-O
-
A73
LVDS_A1+
LVDS Channel A (positive)
DP-O
-
A74
LVDS_A1-
LVDS Channel A (negative)
DP-O
A75
LVDS_A2+
LVDS Channel A (positive)
DP-O
A76
LVDS_A2-
LVDS Channel A (negative)
DP-O
A77
LVDS_VDD_EN
LVDS Panel Power Controller
O-3.3
A78
LVDS_A3+
LVDS Channel A (positive)
DP-O
A79
LVDS_A3-
LVDS Channel A (negative)
DP-O
A80
GND11
Power Ground
PWR
-
-
A81
LVDS_A_CLK+
LVDS Channel A Clock+
DP-O
A82
LVDS_A_CLK-
LVDS Channel A Clock-
DP-O
