Installation PMC240
Page 3 - 6 © 2002 PEP Modular Computers GmbH ID 25270, Rev. 01
3.1.3 Removal Procedures
To remove the PMC240 from the host board proceed as follows:
1. Ensure that the safety requirements indicated above are observed.
2. If applicable, remove the host board from system using host board removal procedures.
3. To remove the PMC240 perform the following referring to Figure 3-1 as required:
1. Obtain host board.
2. Remove the four PMC240 retaining screws.
3. Carefully disengage the Pn1, Pn2, and Pn3 connectors so that no force or movement
is applied to the PMC240 bezel.
4. Ensure that the PMC240 bezel is not jammed or hung up on the host board. If neces-
sary, partially disassemble the host board front panel to free the PMC240 bezel.
5. Slide the PMC240 away from the front panel.
6. Dispose of the PMC240 as required.
4. Dispose of the host board as required.
3.2 Software Installation
Installation of the PMC240 driver software is a function of the application operating system. For
further information refer to the appropriate software documentation.
Warning!
Care must be taken when applying the procedures below to ensure
that neither the PMC240 nor the host board is physically damaged by
the application of these procedures.
