Introduction PMC240
Page 1 - 14 © 2002 PEP Modular Computers GmbH ID 25270, Rev. 01
* Variants: A: single channel, copper
B: dual channel, copper
C: single channel, copper; single channel, optical
D: dual channel, optical
** Operational Configuration: All available channels in operation except where otherwise
noted. All measurements at 33 MHz PCI bus operation.
Software Driver
Information
PCI Header Device ID: 0x1010 (copper); 0x1012 (fiber optic)
Vendor ID: 0x8086
Class Code: 0x020000
Subsystem Device ID: 0x1010 (copper only)
0x1012 (fiber optic only)
0x1011 (copper / fiber optic mixed)
Subsystem Vendor ID: 0x8086
Table 1-3: PMC240 Power Consumption
VARIANT *
POWER CONSUMPTION AT 3.3 V (typical)
OPERATIONAL CONFIGURATION **
NO LINK 10 MBITS 100 MBITS 1000 MBITS
A 380 mA 420 mA 490 mA 980 mA
B 250 mA 310 mA 460 mA 1470 mA
C 460 mA 480 mA
(copper only)
550 mA
(copper only)
1060 mA (copper only)
470 mA (optical only)
1070 mA (both)
D 670 mA — — 700 mA
Table 1-2: PMC240 Main Specifications (Continued)
GROUP TYPE DESCRIPTION
