Installation PMC240
Page 3 - 4 © 2002 PEP Modular Computers GmbH ID 25270, Rev. 01
3.1.2 Installation Procedures
To install the board proceed as follows:
1. Ensure that the safety requirements indicated above are observed.
2. Ensure that the board is properly configured for operation before installing.
3. To install the PMC240 perform the following referring to Figure 3-1 as required:
1. Obtain host board and ensure that it satisfies application requirements and will allow
for proper installation of the PMC240: e.g. connectors match, front panel cutout
matches, holes for mounting screws are available and match, standoffs can be prop-
erly installed, except for prescribed contact points no other contact between host and
PMC240 after mating occurs, etc.
2. Attach the two 10 mm standoffs supplied with the PMC240 to the PMC240.
3. Ensure that the EMC gasket is properly installed on PMC240 bezel.
4. Carefully insert the PMC240 into the front panel cutout of the host board ensuring that
the EMC gasket is properly seated on the front panel.
5. Ensuring that Pn1, Pn2, and Pn3 are properly aligned with Jn1, Jn2, and Jn3 of the
host board, press the PMC240 and host board together so that their connectors are
completely engaged.
6. Install the four PMC240 retaining screws ensuring that the PMC240 is properly mated
to the host board: e.g. PMC bezel flush with front panel, no misalignment of connec-
tors, no contact between host and PMC240 except as prescribed, etc.
4. For installation of the host board with the PMC240 mounted in a system refer to the in-
stallation procedures for the host board.
Warning!
Failure to comply with the instruction below may cause damage to the
board or result in improper system operation.
Warning!
Care must be taken when applying the procedures below to ensure
that neither the PMC240 nor the host board is physically damaged by
the application of these procedures.
Warning!
Proper and safe operation of the PMC240 Dual Gigabit Ethernet Con-
troller depends on the correct configuration of input signals and signal
conditioning. System integrators must ensure that all signals pre-
sented to the PMC240 comply with the specifications set forth in this
manual.
Failure to comply with the above may cause damage to the board or
result in improper system operation.
