PMC240 Introduction
ID 25270, Rev. 01 © 2002 PEP Modular Computers GmbH Page 1 - 13
1.5 Technical Specifications
Table 1-2: PMC240 Main Specifications
GROUP TYPE DESCRIPTION
CONTROLLER
Intel® Gigabit Ethernet
Controller:
82545EM single channel
82546EB dual channel Provides single or dual channel Gigabit Ethernet functionality
including PHY / SERDES and PCI interfacing.
Ethernet standards supported:
• 10Base-T
• 100Base-TX
• 1000Base-T
• 1000Base-SX
Peripheral
Memory
Configuration EEPROM 1 Mbit (64 x 16 organization) EEPROM
Flash Memory Up to 512 kB of soldered Flash memory (optional)
External
Interfaces
Ethernet copper Up to two, 8-contact, female, RJ45 connector(s)
Supports one or two channels of full or half duplex 10Base-T,
100Base-TX, or 1000Base-T Ethernet operation up to 100 meters
cable length.
Ethernet fiber optic Up to two, SC type fiber optic, transceiver connector(s)
Supports one or two channels of full duplex 1000Base-SX Ethernet
operation up to 550 meters link length.
PCI / PCI-X Three, 64-contact, male, PMC connectors (Pn1, Pn2, Pn3)
CMC/PMC standard compliant including:
• 33, 66, and 133 MHz operation
• 32 and 64 bit addressing
• PCI 2.2 and PCI-X 1.0a
Indicators
Front Panel LED Two sets of up to four, green LED’s for indicating Ethernet
channel operational status:
LED1 and LED2:
• ACT: indicates channel activity
• LNK: indicates Ethernet link status
• 100: indicates link speed = 100 M-bits
• 1000: indicates link speed = 1000 M-bits (Gigabit)
General
Mechanical Conforms with CMC: P1386.1/Draft 2.4a, 21-Mar-01
Power Requirements Voltages: board power supply: 3.3 V (± 5%)
V (I/O): 3.3 or 5 V
Power Consumption See Table 1-3 for details
Temperature Range Operational: 0ºC to +70ºC Standard (see note)
Storage: -40ºC to +100ºC
Note: Ethernet controller: 82546EB requires cooling air flow of 1 m/
s or more for operation above 55° C.
Humidity 0% to 95% non-condensing
Dimensions 74 mm x 149 mm single height CMC/PMC card
Board Weight 152 g (2 fiber optic transceivers)
