Page 23
PMC240
Introduction
ID 25270, Rev. 01
© 2002 PEP Modular Computers GmbH
Page 1 - 7
Figure 1-1: System Level Interfacing with PMC Carrier Board
CompactPCI SYSTEM
SYSTEM MASTER
CPCI - BUS
CPCI PMC
Carrier
Board
*
Ethernet
Network
Ethernet
Network
CPCI PMC
Carrier
Board
*
Ethernet
Network
Ethernet
Network
*
* Designates expansion capability if available
