AM4022 Introduction
ID 1052-0183, Rev. 1.0 Page 1 - 13
General
Dimensions Dimensions of the AM4022 without retention screws on front panel:
• Mid-size: 181.5 mm x 73.5 mm x 18.96 mm
• Full-size: 181.5 mm x 73.5 mm x 28.95 mm
Board Weight Mid-size with heat sink and without SATA Flash module: 247 grams
Full-size with heat sink and without SATA Flash module: 310 grams
JTAG Two JTAG interfaces:
• One processor JTAG interface routed to the onboard debug connector
for debugging purposes
• One JTAG interface connected to the AMC Card-edge connector for de-
bugging and manufacturing purposes
S
oftware
Software uEFI BIOS AMI Aptio®, AMI’s next-generation BIOS firmware based on the uEFI
Specification and the Intel Platform Innovation Framework for EFI.
• Serial console redirection via the Serial port or LAN
• LAN boot capability for diskless systems (standard PXE)
• Redundant image; automatic fail-safe recovery in case of a damaged image
• Non-volatile storage of setting in the SPI Flash (battery only required
for the RTC)
• Compatibility Support Module (CSM) providing legacy BIOS compat-
ibility based on AMIBIOS8
• Command shell for diagnostics and configuration
• EFI shell commands executable from mass storage device in a Pre-
OS environment (open interface)
• MMC support in the command shell
Software IPMI Module Management Controller Firmware providing the following features:
• The MMC is accessible via IPMB-L and one KCS interface with interrupt
support
• The MMC Firmware can be updated in field through all supported
onboard interfaces
• Two MMC Flash banks with roll-back capability in case of an upgrade
Firmware failure
• Board supervision and control extensions such as board reset, power
monitor and control, Host Firmware Hub Flash control, and Host boot or-
der configuration
Operating Systems The board is offered with various Board Support Packages including Windows
and Linux operating systems. For further information concerning the operating
systems available for the AM4022, please contact Kontron.
Table 1-2: AM4022 Main Specifications (Continued)
AM4022 SPECIFICATIONS
