AM4022
Introduction
ID 1052-0183, Rev. 1.0
Page 1 - 11
Con
nectors
Front Panel
Connectors
•
One USB 2.0 port on a 5-pin, mini USB Type A connector
•
Two Gigabit Ethernet ports on two RJ-45 connectors
•
One Serial port (COMA) with RS-232 signal level on a 10-pin mini
connector (on the front panel version with a COM port)
•
One 20-pin DisplayPort connector (on the front panel version with a
DisplayPort)
Onboard Connector
•
One extension connector for either Serial ATA Flash or an RTC Backup
Battery module
AMC Card-edge
Connector
•
One 170-pin AMC Card-edge connector
Switches
DIP Switches
•
Two DIP switches for board configuration, SW2 and SW3, consisting of
four switches each
Hot Swap
•
One Hot Swap switch
LEDs
Module Management
LEDs
•
LED1 (red):
Out-of-Service LED
•
LED2 (red/green/amber): Health LED
•
HS LED (blue):
Hot swap LED
User-Specific LEDs
•
ULED3 (red/green):
AMC Ethernet port A link signal status,
AMC port 0 (green) + POST code
•
ULED2 (red/green):
AMC Ethernet port B link signal status,
AMC port 1 (green) + POST code
•
ULED1 (red/green):
SATA channels active (green) + POST code
•
ULED0 (red/green):
POST code
Ethernet LEDs
•
Act (green):
Network / Link Activity
•
Speed (green/yellow):
Network speed
Ti
m
er
Watchdog Timer
•
Software-configurable, two-stage Watchdog with programmable timeout
ranging from 125 ms to 4096 s in 16 steps
•
Serves for generating IRQ or hardware reset
System Timer
•
The Intel® QM77 chipset contains three 8254-style counters which have
fixed uses
•
In addition to the three 8254-style counters, the Intel® QM77 chipset
includes eight individual high-precision event timers that may be used
by the operating system. They are implemented as a single counter
each with its own comparator and value register.
IP
MI
Module Management
Controller
•
ARM7 microcontroller with redundant 512 kB Firmware Flash and auto-
matic roll-back strategy
•
The MMC carries out IPMI commands such as monitoring several
onboard temperature conditions, board voltages and the power supply
status, and managing hot swap operations.
•
The MMC is accessible via a local IPMB (IPMB-L) and one host Key-
board Controller Style Interface (KCS)
•
One MMC system EEPROM for FRU data and firmware private data
Hot Swap
The AM4022 has full hot swap capability.
Table 1-2: AM4022 Main Specifications (Continued)
AM4022
SPECIFICATIONS
