AM5010 Introduction
ID 1022-1107, Rev. 4.0 Page 1 - 13
P R E L I M I N A R Y
General
Power Consumption See Chapter 5, “Power Considerations” for details.
Temperature Range Operational: -5°C to +55°C
Storage: -40°C to +70°C Without battery or any additional components
Mechanical Double, Mid-size module
Dimensions 180.6 mm x 148.5 mm x 18.96 mm
Board Weight Mid-size: 338 grams (without HDD/SSD)
JTAG Two JTAG interfaces:
• One processor JTAG interface routed to the onboard debug connector
for debugging purposes
• One onboard JTAG interface connected to the AMC Card-edge connec-
tor for debugging and manufacturing purposes
Battery The AM5010 is provided with a battery socket for a 3.0V lithium battery for the
RTC.
Recommended type: CR2025
Temperature ranges:
Operational: -20°C to +70°C
typical (refer to the battery manufacturer’s
specifications for exact range)
Storage: -55°C to +70°C typical (no discharge)
Table 1-2: AM5010 Main Specifications (Continued)
FEATURES SPECIFICATIONS
Note ...
When a battery is installed, refer to the operational specifications
of the battery as this will most likely have an influence on the stor-
age temperature of the AM5010 (See "Battery" below).
Note ...
When additional components are installed, refer to their opera-
tional specifications as this will influence the operational and stor-
age temperature of the AM5010.
