1.3 System Relevant Information
The following system-relevant information is general in nature but should still be considered
when developing applications using the AM5010.
1.4 Board Diagrams
The following diagrams provide additional information concerning board functionality and
component layout.
1.4.1 Functional Block Diagram
The following figure shows the block diagram of the AM5010.
Table 1-1: System Relevant Information
SUBJECT INFORMATION
Hardware Requirements The AM5010 can be installed on any AMC-supporting carrier board (with mechan-
ical restrictions) or MicroTCA backplane with the following AMC Card-edge con-
nector port mapping:
• Common Options Region ports 0-1
• Two Gigabit Ethernet SerDes ports
• Common Options Region ports 2-3
• Two Serial ATA ports
• Fat Pipes Region ports 4-7
• PCI Express interface: configurable as either 1x4 or 4x1
• Extended Options Region port 14
• One Debug port
• Extended Options Region port 15
• One Serial port
• Clock
• PCI Express clock reference input, FCLKA
For further information on the AMC interconnection, refer to Chapter 2.4, “AMC
Interconnection”.
PCI Express Configuration The AM5010 only supports the PCI Express root complex configuration; non-
transparent bridge functionality is not supported.
Operating Systems The AM5010 is offered with various Board Support Packages. Please contact Kon-
tron for information concerning the availability of operating systems for the
AM5010.
