AM5010

Introduction

ID 1022-1107, Rev. 4.0

Page 1 - 11

P R E L I M I N A R Y

Onboard

Contro

llers

Gigabit Ethernet

Two Intel® 82571EB Dual Gigabit Ethernet PCI Express bus controllers:

One controller connected to the Common Options Region

One controller connected to Front I/O

VGA / DVI

ATI ES1000 2D graphics controller for enhanced graphics performance:

Supports resolutions of up to 1600 x 1200 pixels at a 75 Hz refresh rate

Digital and analog output

Dedicated 64 MB DDR2 memory

AMC Interconnection

Gigabit Ethernet

Common Options Region ports 0-1

Two Gigabit Ethernet SerDes ports

Serial ATA

Common Options Region ports 2-3

Two Serial ATA 150 ports

PCI Express

Fat Pipes Region ports 4-7

PCI Express interface, configured either as 1x4 or 4x1, operating as a root
complex controller only

Debug Interface

Extended Options Region port 14

One Debug port

Serial Interface

Extended Options Region port 15

One Serial port

Clock Input

Clocks

PCI express clock reference input (FCLKA)

Connecto

rs

Front Panel
Connectors

Two USB 2.0 ports on 4-pin connectors

One Serial port (COM1) with RS232-signal level on RJ45 connector

Two Gigabit Ethernet ports on RJ45 connectors

One DVI -I interface, digital and analog signals

Onboard
Connectors

One SATA connector for optional 2.5” HDD/SSD

One USB 2.0 connector for optional USB 2.0 NAND Flash

AMC Card-edge
Connector

One 170-pin AMC Card-edge connector

Switches

DIP Switches

Three DIP switches for board configuration: one four-position switch, and two
two-position switches

Reset Switch

One front panel hardware reset switch

Table 1-2:

AM5010 Main Specifications (Continued)

FEATURES

SPECIFICATIONS
