Kontron AM4211 User Manual
Page 45
30
www.kontron.com
4
IPMBL State
C3h
(OEM Kontron)
6Fh
(Sensor Specific)
For additional
information, refer to
section Kontron
Offset 2: IPMB-L disabled
Offset 3: IPMB-L enabled
5
MMC Stor Err
28h
(Management
Subsystem
Health)
6Fh
(Sensor Specific)
Generates an event
when a local EEPROM
storage error is
detected.
Offset 1: Controller access
degraded or unavailable
See IPMI v1.5 table 36.3,
Sensor type code 28h for
sensor definition
6
MMC Reboot
24h
(Platform Alert)
03h
(Digital Discrete)
Generates an event
when MMC reboot is
detected.
Offset 0: State Deasserted
Offset 1: State Asserted
7
MMC FWUP
C7h
(Kontron OEM MC
Firmware Upgrade
Status)
6Fh
(Sensor Specific)
Generates events
after IPMI Firmware
upgrade process is
finished
Offset 0: Firmware upgrade in
progress (no event)
Offset 1: Firmware upgrade
succeeded
8
MMC Ver Chg
2Bh
(Version Change)
6Fh
(Sensor Specific)
Generates an event
when the IPMI FW
changes
Offset 1: Firmware / Software
change detected
See IPMI v1.5 table 36.3,
Sensor type code 2Bh (Version
Change) for sensor definition
9
FPGA Ver Chg
2Bh
(Version Change)
6Fh
(Sensor Specific)
Generates an event
when the IPMI FW
changes
Offset 1: Firmware / Software
change detected
10
IPMI Watchdog
23h
(Watchdog 2)
6Fh
(Sensor Specific)
OS Watchdog
Offset 0: Timer expired
Offset 1: Board Reset
Offset 2: Power Down
Offset 3: Power Cycle
Offset 8: Timer Interrupt
See IPMI v1.5 table 36.3,
Sensor type code 23h
(Watchdog 2) for sensor
definition
11
Board Reset
CFh
(OEM Kontron
Reset Sensor)
03h
(Digital Discrete)
Type and source of
Board Reset
Offset 0: Warm Reset
Offset 1: Cold Reset
See OEM sensor table, Sensor
type code CFh for sensor
definition
12
Temp MMC
01h
(Temperature)
01h
(Threshold Based)
Temperature Sensor
of the outlet region
Sensor is only readable when
Payload Power is on
13
Temp NPU
01h
(Temperature)
01h
(Threshold Based)
Temperature Sensor
of the NPU
Sensor is only readable when
Payload Power is on
14
Temp DIMM
01h
(Temperature)
01h
(Threshold Based)
Temperature Sensor
of the DIMM memory)
Sensor is only readable when
Payload Power is on.
15
Vcc +12V
02h
(Voltage)
01h
(Threshold Based)
Voltage on 12v board
power supply
Sensor is only readable when
Payload Power is on.
16
Vcc +5V
02h
(Voltage)
01h
(Threshold Based)
Voltage on 5v board
power supply
Sensor is only readable when
Payload Power is on.
17
Vcc +3.3V
02h
(Voltage)
01h
(Threshold Based)
Voltage on 3.3v board
power supply
Sensor is only readable when
Payload Power is on.
SDR
ID
Name
Sensor Type Code
Reading Type Code
Description
Event Offset
