Kontron KTQ67-FLEX MED - Manual (Page 112)

KTQ67/Flex -Medical Users Guide
KTD-N0849-D Page 112
Function Selection Description
ALS Support
Enabled
Disabled
Valid only for ACPI.
Legacy = ALS Support through the IGD INT10
function.
SCPI = ALS support through an ACPI ALS
driver.
Active LFP
No LVDS
Int-LVDS
SDVO LVDS
eDP Port-A
eDP Port-D
Select the Active LFP Configuration.
No LVDS: VBIOS does not enable LVDS.
Int-LVDS: VBIOS enables LVDS driver by
SDVO encoder.
SDVO LVDS: VBIOS enables LVDS driver by
SDVO encoder.
eDP Port-A: LFP driven by Internal DisplayPort
encoder from Port-A.
Panel Color Depth
18 Bit
24 Bit
Select the LFP Panel Color Depth.
BIOS - Chipset
