KTQ67/Flex -Medical Users Guide
KTD-N0849-D Page 10
2 System Specification
2.1 Component main data
The table below summarizes the features of the KTQ67/Flex –Medical embedded motherboard.
Form factor KTQ67/Flex-Medical: Flex-ATX (190,5 mm by 228,6 mm)
Processor Support the following Intel® Core™ processors via Socket H2 (LGA1155), ZIF Socket
• Intel® Core™ i7, 2
nd
and 3
rd
Generation
• Intel® Core™ i5, 2 nd
and 3
rd
Generation
• Intel® Core™ i3, 2 nd
and 3
rd
Generation
• Intel® Pentium® Desktop
• 1066/1333MHz system bus and 3/6/8MB internal cache.
(Intel® Pentium® Desktop G622 only 1066MHz)
• Up to 95W (Thermal Guideline)
Memory • 4x DDR3 UDIMM 240pin socket
• Support single and dual ranks DDR3 1066/1333MT/s
(PC3-8500/PC3-10600)
• Support system memory from 256MB and up to 4x 8GB
Note: Less than 4GB displayed in System Properties using 32bit OS
(Shared Video Memory/PCI resources is subtracted)
• ECC not supported (chipset limitation)
Chipset Intel Q67 PCH (Platform Controller Hub)
• Intel ® VT-d (Virtualisation Technology for Directed I/O)
• Intel ® TXT (Trusted Execution Technology)
• Intel ® vPRO
• Intel ® AMT (Active Management Technology) version 8
• Intel ® AT (Anti-Theft Technology)
• Intel ® HD Audio Technology
• Intel ® RST (Rapid Storage Technology)
• Intel ® RRT (Rapid Recover Technology)
• SATA (Serial ATA) 6Gb/s and 3Gb/s.
• USB revision 2.0
• PCI Express revision 2.0
• ACPI 3.0b compliant
• Dual Display support (Dual Graphic Pipes)
• Blue-ray HD video playback
Security • Intel® Integrated TPM 1.2 support
Management • Intel® Active Management Technology (Intel® AMT) 8.0
Audio Audio, 7.1 Channel High Definition Audio Codec using the VIA 1708B codec
• Line-out
• Line-in
• Surround output: SIDE, LFE, CEN, BACK and FRONT
• Microphone: MIC1 and MIC2
• CDROM in
• SPDIF (electrical Interface only)
• On-board speaker (Electromagnetic Sound Generator like Hycom HY-05LF)
System Specification
