User Guide
CP6005(X)-SA
Gener
al
Power Consumption
See Chapter 4 for details.
Temperature Range
Operational:
0°C to +60°C
Standard
-40°C to +70°C
Extended
Storage:
-40°C to +85°C
Without hard disk and without battery
Battery
3.0 V lithium battery for RTC with battery socket
Battery type: UL-approved CR2025
Temperature ranges:
Operational (load):
-20°C to +70°C
typical
(refer to the battery manufacturer’s
specifications for exact range)
Storage (no load):
-40°C to +70°C
typical
Climatic Humidity
93% RH at 40 °C, non-condensing (acc. to IEC 60068-2-78)
Dimensions
233.35 mm x 160 mm
6U, 4 HP, CompactPCI Serial-compliant form factor
Board Weight
CP6005-SA with heat sink: 778 grams
CP6005X-SA with heat sink: 796 grams
The above-mentioned board weight refers to the CP6005(X)-SA without extension
modules such as the SATA Flash module or the MMADP-SATA01 module.
Table 1: CP6005(X)-SA Main Specifications (Continued)
FEATURES
SPECIFICATIONS
