3 board layout, Board layout, 4 hp cp6005-sa board layout (top view) – Kontron CP6005X-SA User Manual
Page 15
D R A F T — F O R I N
T E R N A L U S E O N L Y
15
www.kontron.com
User Guide
CP6005(X)-SA
1.3.3 Board Layout
Figure 3: 4 HP CP6005-SA Board Layout (Top View)
4
th
Gen.
Intel® Core™ i7/i5
Battery
J12
GbE E
J11
GbE B
J10
GbE A
J14
J16
J15
IPMI/WD/TH LEDs
GP/POST CODE LEDs
J17
J18
J19
J5
J3
J2
J1
J13
J6
HS LED
J7
J8
J9
J20
J21
Intel® QM87
SATA Flash Module
MMADP-
SATA01
Module
Intel®
I350
Magnetics
Magnetics
HDD/SSD
PMC/XMC
