1.4 Technical Specif ication
Table 1: CP6005(X)-SA Main Specifications
FEATURES SPECIFICATIONS
Pr
ocess
or &
Chipse
t
CPU & Graphics Controller The CP6005(X)-SA supports the following 4 th generation processors:
» Quad-core Intel® Core™ i7-4860EQ (SV), 1.8 GHz, 6 MB L3 cache, GT3e, In-
tel® Iris™ Pro Graphics 5200
» Quad-core Intel® Core™ i7-4700EQ (SV), 2.4 GHz, 6 MB L3 cache, GT2, Intel®
HD Graphics 4600
» Dual-core Intel® Core™ i5-4400E (SV), 2.7 GHz, 3 MB L3 cache, GT2, Intel®
HD Graphics 4600
PCH Intel® QM87 Chipset
Me
mor
y
Main Memory Up to 16 GB, dual-channel DDR3 SDRAM memory with ECC running at 1600 MHz on
two SODIMM sockets
Flash Memory Two 16 MB SPI boot flash chips for two separate uEFI BIOS images
Up to 64 GB SLC NAND flash via an onboard SATA Flash module (SSD)
EEPROM EEPROM with 64 kbit
Inte
rf
aces
CompactPCI CompactPCI interface:
» Compliant with CompactPCI Specification PICMG 2.0 R 3.0:
» System controller operation
» 64-bit / 66 MHz PCI or PCI-X master interface with dedicated PCIe-to-PCI-
X bridge
» 3.3V or 5V signaling levels (universal signaling support)
» Compliant with the Packet Switching Specification PICMG 2.16.
The CP6005(X)-SA supports System Master hot swap functionality and applica-
tion-dependent hot swap functionality when used in a peripheral slot.
When used as a System Master, the CP6005(X)-SA supports individual clocks for
each slot and the ENUM signal handling is in compliance with the PICMG 2.1 Hot
Swap Specification.
When installed in a peripheral slot, the CP6005(X)-SA is isolated from the Com-
pactPCI bus. It receives power from the backplane and supports rear I/O and, if
the system supports it, packet switching (in this case up to two channels of Giga-
bit Ethernet).
Standard Rear I/O The following interfaces are routed to the rear I/O connectors J3 and J5.
COMA (RS-232 signaling) and COMB (RS-232 signaling); no buffer on the rear I/O
module is necessary
» 4 x USB 2.0
» 1 x CRT VGA, 2 x HDMI/DVI
» 1 x HDA
» 2 x Gigabit Ethernet (compliant with PICMG 2.16, R 1.0)
» 4 x SATA 3 Gb/s
» 4 x GPIs and 4 GPOs (LVTTL signaling)
» System write protection
