User Guide

CP6005(X)-SA

Sock

Onboard Connectors

» One XMC connector, J19 (P15)
» Two SATA connectors

» One 7-pin, standard SATA connector, J14
» One 34-pin, SATA extension connector, J16

» One JTAG connector, J15
» One XDP-SFF (debug) connector, J25
» Four CompactPCI connectors J1, J2, J3 and J5
» Two ZDplus high-speed serial rear I/O connectors, J4 and J41 (PICMG 2.20)

(CP6005X-SA)

» Two 204-pin DDR3L SODIMM sockets, J17 and J18

LEDs

Front Panel LEDs

IPMI LEDs:

» I0/I1 (red/green):

Software status of the IPMI controller

System Status LEDs:

» WD (green):

Watchdog status

» TH (red/green):

Temperature status

» HS (blue):

Hot swap status

General Purpose LEDs:

» LED3–0 (red/green/amber):

General purpose / POST code

Ethernet LEDs:

» ACT (green):

Network link / activity

» SPEED (green/orange):

Network speed

Switches

DIP Switches

Two onboard DIP switches, SW1 and SW2 for board configuration on the rear side
of the board

Reset Switch

One hardware reset switch on the front panel

Hot Swap Switch

One switch for hot swap purposes integrated in the front panel in accordance
with PICMG 2.1 Rev. 2.0

Real-Time Clock

Real-time clock with 256 Byte CMOS RAM; battery-backup available

Watchdog Timer

Software-configurable, two-stage Watchdog with programmable timeout ranging
from 125 ms to 4096 s in 16 steps
Serves for generating IRQ or hardware reset

System Timer

The Intel® QM87 Chipset contains three 8254-style counters with fixed uses.
In addition to the three 8254-style counters, the Intel® QM87 Chipset includes
eight individual high-precision event timers that may be used by the operating
system. They are implemented as a single counter each with its own comparator
and value register.

IPMI

IPMI Controller

NXP® ARM7 microcontroller with 512 kB firmware flash and automatic rollback
strategy
The IPMI controller carries out IPMI commands such as monitoring several
onboard temperature conditions, board voltages and the power supply status,
and managing hot swap operations.
The IPMI controller is accessible via two IPMBs, one host Keyboard Controller
Style (KCS) Interface and up to four Gigabit Ethernet Interfaces (IOL).

Table 1: CP6005(X)-SA Main Specifications (Continued)

FEATURES

SPECIFICATIONS
