VMP2
VMP1-IO1 Module (Optional)
ID 24855, Rev. 02
Page A - 5
© 2002 PEP Modular Computers GmbH
A.3 Board Layout
The VMP1-IO1 has two onboard connectors (CON9 and CON10) which provide all the
PCI signals and the power supply for the PMC module.
Figure A-1: Board Layout (Front View)
1
100
99
2
PCI EXPANSION CONNECTOR
1
2
63
64
1
2
63
64
DC/DC
MAGNIFIED
