PB-DOUT8
Page 1 - 6
Introduction
22 Oct 98 Man. ID 17984, Rev. Index 0110
1.5 Technical Specification
Table 1-1: PB-DOUT8 Technical Specification
PB-DOUT8 Specification
Channels and Channel
Grouping 4 groups of channels, each consisting of
- 2 channels with high-side switches
- 2 channels with low-side switches
Isolation Voltages Group-to-group: 0.7 mm (0.7 kV)
Group-to-VMEbus:4.0 mm (4.0 kV)
Input Voltage Range: 10...40 V DC
Nominal: 24 V DC
Power Consumption 24V side:typ. 2mA per group
VMEbus side:typ. 95 mA
Temperature Range:
- Standard Operation
- Extended Operation
- Storage
0° to + 70°C
- 40° to + 85°C
- 55° to + 125°C
Driving Current Typically: 1.3 A DC (low side),
1.8 A DC (high side)
Minimum (LS/HS): 1.0 A DC (0...+70°C)
0.6 A DC (-40...0°C)
Maximum (typ.) 4.0 A (low side),
5.0 A (high side)
Open Circuit Detection Typ. 30 µA
Operating Frequency 0...250 Hz, incl. inductive load
Inductive Load 24 V/0.5 A/1,0 Henry
On-State Resistance Typically: 250 mOhm (low side),
220 mOhm (high side)
Switching Speed Typ. 1 ms, incl. status feedback
