Pinouts of front panel adapter connectors - 15, Cp346 rear i/o modules – Kontron CP346 User Manual

Page 69

background image

CP346

Rear I/O Modules

ID 27253, Rev. 03

© 2005 Kontron Modular Computers GmbH

Page 5 - 15

P R E L I M I N A R Y

Table 5-5: Pinouts of Front Panel Adapter Connectors (Sheet 1 of 2)

50-Pin Row

Connector

RS422/RS485

Half Duplex

9-Pin Row

Connectors

Channel

1

TRxD+

3

0

26

TRxD-

8

2

—

—

27

—

—

3

—

1

28

—

6

4

—

—

29

—

—

5

—

7

30

—

4

6

GND

5

31

—

2

7

TRxD+

3

1

32

TRxD-

8

8

—

—

33

—

—

9

—

1

34

—

6

10

—

—

35

—

—

11

—

7

36

—

4

12

GND

5

37

—

2

13

TRxD+

3

2

38

TRxD-

8

14

—

—

39

—

—

15

—

1

40

—

6

16

—

—

41

—

—

17

—

7

42

—

4

18

GND

5

43

—

2
