CP346 Introduction
ID 27253, Rev. 03 © 2005 Kontron Modular Computers GmbH Page 1 - 11
P R E L I M I N A R Y
1.5 Applied Standards
The Kontron Modular Computers’ CompactPCI systems comply with the requirements of the
following standards:
Humidity 93% RH at 40°C non-condensing
Dimensions • 100mm x 160mm
Weight CP346: 140 g
CP346-OPT: 145 g
Table 1-3: Applied Standards
COMPLIANCE TYPE STANDARD
Test Level
(Ruggedized Version)
CE Emission EN55022
EN61000-6-3 --
Immission EN61000-6-2
EN55024 --
Electrical Safety EN60950-1 --
Mechanical Mechanical Dimensions IEEE 1101.10 --
Environmental
Aspects Vibration (Sinusoidal) IEC60068-2-6 2g/12-300Hz/10
acceleration / frequency range /
test cycles per axis
Random Vibration
(Broadband) IEC68-2-64 20-500Hz,0.05g²/500-2000Hz,
0.005g²/3.6g rms/3/30min
frequency range1 / frequency range2
/acceleration / cycle / duration
Permanent Shock IEC60068-2-29 15g/11ms/500/1s
peak acceleration / shock duration
half sine / number of shocks /
recovery time
Single Shock IEC60068-2-27 30g/9ms/18/5s
peak acceleration / shock duration /
number of shocks / recovery time in
sec.
Climatic Humidity IEC60068-2-78 93% RH at 40°C, non-condensing
RoHS Directive 2002/95/EC Restriction of the use of certain
hazardous substances in electrical
and electronic equipment
Important...
The values in the above table are valid for boards which are ordered with the
ruggedized service. For more information please contact your local Kontron
office.
Table 1-2: CP346 Technical Specification (Sheet 2 of 2)
CP346 Specification
