Introduction
CP346
Page 1 - 8
© 2005 Kontron Modular Computers GmbH
ID 27253, Rev. 03
P R E L I M I N A R Y
1.3.3
Board Layouts
Figure 1-3: CP346 Board Layout
– Standard Variant
Figure 1-4: CP346 Rear I/O Variant
LEDs
CHANNEL 0
CHANNEL 1
CHANNEL 2
CHANNEL 3
CLOCK
SUPPLY
CON3
SERIAL
CONTROLLER
OPTIONAL
EEPROM
RS422/
RS485
RS232
J1
J2
J3
J4
J5
J6
J7
J8
S1
DIP SWITCH
1
8
ON
CPLD
LOGIC
R7
R14
LED DRIVERS
R67
R66
R68
R70
R69
R65
R64
R63
REAR I/O
FRONT I/O
TTL ROUTING OPTION
LEDs
CLOCK
SUPPLY
SERIAL
CONTROLLER
OPTIONAL
EEPROM
LED DRIVERS
REAR I/O
FRONT I/O
TTL ROUTING OPTION
