Engine/
Transmis-
sion
Axle Model GCWR (Gross
Combined Wt.
Rating)
Frontal Area Max. GTW
(Gross Trailer
Wt.)
Max. Trailer
Tongue Wt.
(See Note)
3.8L/
Automatic
3.73 4–Door
X Model
(2WD)
7,734 lbs (3 508 kg) 32 sq ft (2.97 sq m) 3,500 lbs
(1 587 kg)
350 lbs (159 kg)
3.8L/
Automatic
3.73 4–Door
Sahara
Model
(2WD)
7,893 lbs (3 580 kg) 32 sq ft (2.97 sq m) 3,500 lbs
(1 587 kg)
350 lbs (159 kg)
3.8L/
Manual
3.21 4–Door
X Model
(4WD)
5,431 lbs (2 463 kg) 32 sq ft (2.97 sq m) 1,000 lbs (453 kg) 100 lbs (45 kg)
3.8L/
Manual
3.73 4–Door
X Model
(4WD)
7,931 lbs (3 597 kg) 32 sq ft (2.97 sq m) 3,500 lbs
(1 587 kg)
350 lbs (159 kg)
3.8L/
Automatic
3.73 4–Door
X Model
(4WD)
7,932 lbs (3 598 kg) 32 sq ft (2.97 sq m) 3,500 lbs
(1 587 kg)
350 lbs (159 kg)
5
STARTING AND OPERATING 367
