Jeep 2009 Wrangler Unlimited - Owner Manual - Manual (Page 367)

Trailer Towing Weights (Maximum Trailer Weight Ratings)
The following chart provides the maximum trailer weight ratings towable for your given drivetrain.
Engine/
Transmis-
sion
Axle Model GCWR (Gross
Combined Wt.
Rating)
Frontal Area Max. GTW
(Gross Trailer
Wt.)
Max. Trailer
Tongue Wt.
(See Note)
3.8L/
Manual
3.21 2–Door
X Model
(4WD)
5,049 lbs (2 290 kg) 25 sq ft (2.32 sq m) 1,000 lbs (453 kg) 100 lbs (45 kg)
3.8L/
Manual
3.73 2–Door
X Model
(4WD)
6,049 lbs (2 744 kg) 25 sq ft (2.32 sq m) 2,000 lbs (907 kg) 200 lbs (91 kg)
3.8L/
Automatic
3.73 2–Door
X Model
(4WD)
6,051 lbs (2 745 kg) 25 sq ft (2.32 sq m) 2,000 lbs (907 kg) 200 lbs (91 kg)
3.8L/
Manual
3.21 2–Door
Sahara
Model
(4WD)
5,231 lbs (2 373 kg) 25 sq ft (2.32 sq m) 1,000 lbs (453 kg) 100 lbs (45 kg)
5
STARTING AND OPERATING 365
