ACCESSORIES
38
ARCHON
The ARCHON speakers use only with FBT mount for wall installation.
USE WITH OTHER MOUNTS IS CAPABLE OF RESULTING IN INSTABILITY CAUSING POSSIBLE INJURY.
AC-U110V
8.
77 inch
21.92 inch
2.
75 inch
AC-U110H
14
.1 inch
12.8 inch
2.
75 inch
110
4.46 inch 4.46 inch
8.99 inch 8.99 inch
ARCHON speakers can be installed as follow:
> Suspension by wall bracket ( 110 / 112 / 115 / 208S )
> Installation on tripod stand
> Installation with adjustable wall support ( 105 / 106 / 108 )
> Simple stack installation ( 208S / 215S )
( 110 / 112 / 115 )
